Gas Solenoid Valve – 500 mbar, IP65, Flow Adjustment, Class A

The HONEYWELL KROMSCHRODER VAS8100F05NWB/PP/MM is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in a closed position when de-energized and is rated for operation at pressures up to 500 mbar. The unit features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. This model is certified according to EU, FM, and CSA standards; compatible with systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
