Gas Solenoid Valve - 500 mbar, IP65, SIL 3, FM/CSA

The HONEYWELL KROMSCHRODER VAS350F/NWGL is a Class A solenoid valve intended for use in automatic shut-off applications involving gas and air. It remains closed when not energized. The unit is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment features. This model has been evaluated according to SIL 3 and PL e requirements, with approvals from FM and CSA.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Enclosure is rated IP65 according to IEC standard
• Available versions offer options such as position indicators, visual indicators, bypass/pilot gas valves, or integrated pressure switches
