Gas Solenoid Valve – 500 mbar, IP65, SIL 3 Rated, VAS Series

The HONEYWELL KROMSCHRODER VAS780F05LWB/PP/PP is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. When not energized, the valve is in a closed position as per design specifications and operates at a maximum pressure of 500 mbar. It features a pilot lamp, flow adjustment, and an IP65-rated enclosure. The unit is certified according to applicable EU, FM, and CSA standards; rated for use in systems with requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
