Gas Solenoid Valve – 500 mbar, IP65, SIL 3/PL e, FM/CSA

The HONEYWELL KROMSCHRODER VAS2-/25R/NWSR is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This valve remains closed when de-energized and is rated for operation at a maximum pressure of 500 mbar. Equipped with pilot lamp, adjustable flow settings, and an enclosure rated to IP65. Certified according to applicable EU standards; FM and CSA approved, with compatibility for systems requiring up to SIL 3 or PL e compliance.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
