Gas Solenoid Valve - ANSI Flange, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS7T80A05LWE is a solenoid valve intended for use in the control of gas and air flow, with automatic shut-off functionality as specified by manufacturer guidelines. Classified as a Class A valve to EN 161 standards, it remains closed when de-energized and rated for operation at pressures up to 500 mbar as per product specifications. This model features ANSI flange connections in size 7, includes a pilot lamp for status indication, flow adjustment capability, and has an ingress protection rating of IP65 according to applicable standards. It holds EU certification along with FM and CSA approvals, and is certified for use in systems up to SIL 3 and PL e.

Key features:

• Valve Size: 7 (DN range from 10 to 125)
• Connection Type: ANSI flange
• Operating Pressure: Up to 500 mbar
• Electrical Options: Available in mains voltages of 24 V DC, 120 V AC or 230 V AC; terminal electrical connection
• Operation Mode: Quick opening/closing or slow opening/quick closing options available
• Status Indication: Pilot lamp included
• Certifications: EU certified; FM & CSA approved; suitable for SIL 3 / PL e systems
• Protection Rating: IP65
