Gas Solenoid Valve - Class A, 500 mbar, EN 161, IP65

The HONEYWELL KROMSCHRODER VAS115/-R/NKGR is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow, conforming to EN 161 standards. This valve remains closed when de-energized and features a pilot lamp and flow adjustment capability. It operates at a maximum pressure of 500 mbar and carries certifications including EU, FM, CSA, as well as suitability for systems up to SIL 3 and PL e. The unit is rated IP65 according to applicable standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
