Gas Solenoid Valve – Class A, 500 mbar, EN 161, IP65

The HONEYWELL KROMSCHRODER VAS2T32/-N/NWGL is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air, in accordance with EN 161 standards. The valve is configured to be in a closed position when not energized and features a pilot lamp and flow adjustment. It is rated for operation at pressures up to 500 mbar and certified according to applicable EU, FM, and CSA standards. The unit is compliant with specifications for systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
