Gas Solenoid Valve – Class A, 500 mbar, EN 161, IP65

The HONEYWELL KROMSCHRODER VAS3-/50R/NK is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air lines. This unit conforms to EN 161 standards, remaining closed when de-energized. It features a maximum operating pressure of 500 mbar and includes both a pilot lamp and flow adjustment capability. The valve carries EU certification as well as FM and CSA approvals, compatible with systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: available with various opening/closing actions as specified by manufacturer
• Mains voltage compatibility: available for 24 V DC, 120 V AC, or 230 V AC supply
• Electrical connection via terminal block
• Protection rating: IP65
