Gas Solenoid Valve - Class A, 500 mbar, EN 161, IP65
Mfr # KS88202975
Zoro # G215426081
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS8T100A05NLQGLE/MMVM/MMMM is a Class A solenoid valve intended for use in automatic shut-off applications in gas and air systems. It operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. The unit features an integrated pilot lamp and flow adjustment capabilities, including flow adjustment capabilities. This model is certified to EU standards as well as FM and CSA approvals, and it meets SIL 3 and PL e certification levels.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Protection rating: IP65
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
