Gas Solenoid Valve – Class A, 500 mbar, EN 161, IP65 Rated

The HONEYWELL KROMSCHRODER VAS2-/40R/NWSL is a Class A solenoid valve. It is intended for use in automatic shut-off applications involving gas and air. This valve meets the requirements of EN 161 standards, remaining closed when not energized. The unit has a maximum rated operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment options. It is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals. It is also certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
