Gas Solenoid Valve – Class A, 500 mbar, EN 161, IP65, VCS Series

The HONEYWELL KROMSCHRODER VCS8100F05NLWRB/2-P3/PPPP is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve conforms to EN 161 standards, is rated to remain closed when de-energized, and has a maximum operating pressure rating of 500 mbar. It includes pilot lamp indication and flow adjustment options. The unit carries IP65 ingress protection, is EU certified, FM and CSA approved, and holds certification for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valves, or integrated pressure switches
