Gas Solenoid Valve – Class A, 500 mbar, Fast Opening/NC

The HONEYWELL KROMSCHRODER VAS3 Solenoid Valve is a Class A gas safety valve designed for automatic shut-off in gas and air systems. It operates as a normally closed valve, remaining closed when de-energized, and includes a fast opening mechanism. The unit supports maximum operating pressure up to 500 mbar and includes both pilot lamp indication and flow adjustment capabilities. Certified under EN 161.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Maximum operating pressure: 500 mbar
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valves, or integrated pressure switches
