Gas Solenoid Valve - Class A, 500 mbar, IP65, DN10-125

The HONEYWELL KROMSCHRODER VAS125/-R/NK is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It compliant with EN 161 standards and is normally closed when not energized. This model is rated for a maximum operating pressure of 500 mbar, features an integrated pilot lamp and flow adjustment, and has an ingress protection rating of IP65. The valve holds certifications including SIL 3 and PL e, with EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing operation: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
