Gas Solenoid Valve – Class A, 500 mbar, IP65, DN10-125
Mfr # KS88011660
Zoro # G915415439
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS1T20N/NWSL is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve remains closed when de-energized and is rated for operation up to a maximum pressure of 500 mbar. It features a pilot lamp, flow adjustment, and is rated IP65 according to IEC standard for protection against dust and water ingress. The unit is certified in accordance with applicable EU, FM, and CSA standards, with suitability for integration into systems with requirements up to SIL 3 or PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
