Gas Solenoid Valve - Class A, 500 mbar, IP65, DN10-125
Mfr # KS88027097
Zoro # G815421936
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS340R/NWGL is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It compliant with EN 161 standards, the valve position is closed when not energized, and it is rated for a maximum operating pressure of 500 mbar. The unit includes pilot lamp and adjustable flow settings, with an IEC standard-rated IP65 ingress protection rating. It is certified by relevant EU, FM, and CSA authorities and suitable for integration into systems requiring compliance up to SIL 3 or PL e.
Key features include:
- Size range: 1 to 9; nominal diameter (DN): 10 to 125
- Connection options: threaded or flanged
- Opening/closing types: quick opening/quick closing or slow opening/quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
