Gas Solenoid Valve – Class A, 500 mbar, IP65, DN10–125

The HONEYWELL KROMSCHRODER VAS110R/NKGR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This unit remains closed when not energized. It is rated for a maximum operating pressure of 500 mbar and equipped with pilot lamp and flow adjustment. The valve is rated IP65 for ingress protection and certified to applicable EU, FM, and CSA standards. It is suitable for installation in systems requiring compliance up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
