Gas Solenoid Valve – Class A, 500 mbar, IP65, DN10–125

The HONEYWELL KROMSCHRODER VAS2T25N/NW is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve remains closed when de-energized and rated for operation up to a maximum pressure of 500 mbar. It features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. The unit holds EU certification as well as FM and CSA approvals, with may be used in systems where SIL 3 or PL e compliance is required, subject to proper system integration.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick-opening/quick-closing or slow-opening/quick-closing actuation options
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
