Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS240F/LWSR is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. This valve meets EN 161 standard requirements and is normally closed (de-energized state). It features a maximum operating pressure of 500 mbar and includes both a pilot lamp and flow adjustment capability. The unit is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals. It holds certification meeting SIL 3 and PL e requirements.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection types: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
