Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS110R/NWGL is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow via automatic shut-off mechanisms. It operates in accordance with EN 161 standards and remains closed when de-energized. The unit supports a maximum operating pressure of 500 mbar, includes adjustable flow settings, and is equipped with a pilot lamp that indicates operational status. It is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals.

Key features:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Provides electrical connection through terminal block
• Available in configurations including position indicator, visual indicator, integrated bypass/pilot gas valve option(s), or integrated pressure switches DG../VC
• Certified according to SIL3 and PL e standards
