Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS1W0R/NW is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It meets the requirements set forth in EN 161 standards, configured to remain closed when not energized, and rated for a maximum operating pressure of 500 mbar. The unit includes a pilot lamp and adjustable flow settings, with an ingress protection rating of IP65. This model is certified for use in systems up to SIL 3 and PL e, and holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches
