Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS250/-R/NWGR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve operates in a closed position when de-energized and is certified to EN 161 standards. It supports maximum operating pressures up to 500 mbar, features an integrated pilot lamp and flow adjustment, and has an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, compatible with systems that specify SIL 3 or PL e requirements.

Key features:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
