Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS3-/50R/LWGR is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air. This unit operates in accordance with EN 161 standards, remaining closed when not energized. It is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment options. The valve is rated to IP65 ingress protection standard, certified by EU, FM, and CSA, and is suitable for installation in systems with requirements up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
