Gas Solenoid Valve, Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS2-/40R/LWGR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards, remaining closed when not energized. This valve supports a maximum operating pressure of 500 mbar and includes features such as a pilot lamp and flow adjustment. The unit is rated IP65 for ingress protection and certified to applicable EU, FM, and CSA standards. It is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing operation types
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided via terminal block
• Available versions include models equipped with position indicator, visual indicator, bypass/pilot gas valve fittings, or pressure switches
