Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VCS665F05NLKR3E/PPZ-/PPPP is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air, conforming to EN 161 standards. This valve is configured to be closed when not energized and is rated for operation at pressures up to 500 mbar. It features an integrated pilot lamp and flow adjustment, offers protection rated at IP65, and holds EU certification as well as FM and CSA approvals. The product is certified for systems requiring up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valves, or pressure switches
