Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Certified
Mfr # KS88205349
Zoro # G615418709
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS665F05LWGRB/MM/MM is a Class A solenoid valve intended for use in the control of gas and air line flow. This valve operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. It includes an integrated pilot lamp for status indication and adjustable flow settings, offering visual status indication and precise control over flow rates. The unit is rated to IP65 for ingress protection and holds EU certification as well as FM and CSA approvals.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
- Certified for use in systems up to SIL 3 and PL e
