Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161 Certified
Mfr # KS88207327
Zoro # G015426021
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS8100F05NNWLB/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. When not energized, the valve is in a closed position and operates at a maximum pressure of 500 mbar. It features an integrated pilot lamp, includes adjustable flow settings as specified by manufacturer parameters, and is rated to IP65 for ingress protection. The unit meets EN 161 standards and holds EU certification as well as FM and CSA approvals. It is certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Opening/closing types: quick opening with quick closing or slow opening with quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
