Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161 Compliant

The HONEYWELL KROMSCHRODER VAS2-/25R/NW is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. The unit features a pilot lamp for status indication and adjustable flow settings, offering visual status indication and operational flexibility. This model has been evaluated according to SIL 3 and PL e standards, with approvals from FM and CSA.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators, fitted bypass/pilot gas valves, or integrated pressure switches
