Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161, FM/CSA Approved

The HONEYWELL KROMSCHRODER VAS1-/15R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit compliant with EN 161 standards, is closed when not energized. It features a maximum operating pressure of 500 mbar and includes both a pilot lamp and adjustable flow settings. The valve is rated IP65 for ingress protection, holds EU certification, and has FM and CSA approvals. It also holds certification meeting requirements for SIL 3 and PL e classified systems.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
