Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS115R/NK is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air in accordance with EN 161 standards. This valve remains closed when de-energized and is equipped with a pilot lamp and adjustable flow control. It is rated for operation at pressures up to 500 mbar, has an IP65 ingress protection rating, and is certified according to EU, FM, and CSA standards. The unit is certified for application in systems requiring SIL 3 or PL e compliance.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided by terminal block
• Available versions include models equipped with position indicator, visual indicator, bypass/pilot gas valve fittings, or pressure switches DG../VC
