Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS1T25/-N/NQSR is a Class A solenoid valve rated for automatic shut-off of gas and air as specified by EN 161 standards. The valve is configured to be closed when not energized and features a pilot lamp, flow adjustment, and an IP65-rated enclosure. It holds certifications including SIL 3, PL e, FM, CSA, and relevant EU directives.

Key features include:

• Maximum operating pressure: 500 mbar
• Available sizes: DN10–DN125
• Connection types available: threaded or flanged
• Operation modes available include quick opening/closing or slow opening/quick closing
• Rated mains voltages supported are: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided via terminal block
• Optional configurations may include position indicator(s), visual indicator(s), bypass/pilot gas valve(s), or pressure switch(es)
