Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS225/-R/NP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It compliant with EN 161 standards and is normally closed (de-energized state). This valve rated for a maximum operating pressure of 500 mbar, features an integrated pilot lamp and flow adjustment, and has an ingress protection rating of IP65. The unit certified to applicable EU, FM, and CSA standards, and it is suitable for installation in systems requiring up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
