Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS1-0/NW is a Class A solenoid valve intended for use in automatic shut-off applications involving gas and air. This unit operates in accordance with EN 161 standards, remaining closed when not energized. It includes a pilot lamp and adjustable flow control, rated for maximum operating pressure of 500 mbar, and has an ingress protection rating of IP65. The valve is certified to applicable EU, FM, and CSA standards and is suitable for installation in systems requiring SIL 3 or PL e certification.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
