Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161
Mfr # KS88018202
Zoro # G815417458
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS120/-R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates within the parameters specified by EN 161 standards; remains closed when not energized, and is rated for a maximum operating pressure of 500 mbar. The unit includes a pilot lamp and adjustable flow settings, with an IP65 rating for ingress protection. This model holds certifications in accordance with applicable EU, FM, and CSA regulatory requirements, and it is suitable for integration into systems with requirements up to SIL 3 or PL e.
Key features include:
- Size range: 1 to 9
- Nominal diameter (DN): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
