Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS3T40/-N/NKGR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit conforms to EN 161 standards, is normally closed when not energized, and features a maximum operating pressure of 500 mbar. It includes both a pilot lamp and adjustable flow. The valve is rated IP65 for ingress protection, holds EU certification, FM and CSA approvals, and is certified as meeting requirements for SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: quick opening/quick closing or slow opening/quick closing available
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
