Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS350/-F/NK is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air, conforming to EN 161 standards. This valve remains closed when de-energized and includes a pilot lamp and adjustable flow settings. It is rated for operation at maximum pressure of 500 mbar and has an IP65 rating. The unit holds EU certification as well as FM and CSA approvals, and it is certified up to SIL 3 (Safety Integrity Level) and PL e (Performance Level).

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing mechanisms
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Equipped with terminal block electrical connection
• Available in versions featuring position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
