Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS350/-R/NW is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve meets the requirements of EN 161 standards and is configured to remain closed when de-energized. It features a maximum operating pressure of 500 mbar and includes both a pilot lamp and flow adjustment capabilities. The unit is rated to IP65, carries EU certification, FM and CSA approvals, and has been assessed according to SIL 3 and PL e criteria.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
