Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161
Mfr # KS88203230
Zoro # G215424292
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS780F05LWB/PP/MM is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve operates in accordance with EN 161 standards, remaining closed when de-energized. It supports a maximum operating pressure of 500 mbar and features both pilot lamp indication and flow adjustment capabilities. The unit is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals, making it suitable for use in systems compliant with requirements applicable to systems rated up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
