Gas Solenoid Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VCS780F05NNWR3B/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This unit conforms to EN 161 standards and is normally closed when not energized. It features a maximum operating pressure of 500 mbar, rated IP65 for ingress protection, and holds certification meeting requirements for SIL 3 and PL e. The valve includes a pilot lamp and adjustable flow settings.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: quick opening, quick closing or slow opening, quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
