Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS665F05NW3B/MM/MM is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air, conforming to EN 161 standards. This unit is configured to be closed when not energized and features a pilot lamp and flow adjustment. It is rated for maximum operating pressure up to 500 mbar, with an IP65 enclosure rating, and holds certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing operation types
• Rated mains voltage: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection through terminal block
• Versions available with position indicator, visual indicator, integrated bypass/pilot gas valve option, and integrated pressure switches DG../VC
