Gas Solenoid Valve – Class A, 500 mbar, IP65, EN 161, SIL 3 Certified
Mfr # KS88206546
Zoro # G815425514
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS8100F05NLKR3E/PPPP/PPZ- is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. It meets EN 161 standards; valve is closed when not energized, and supports a maximum operating pressure of 500 mbar. The unit includes pilot lamp indicator and adjustable flow settings, with an IP65 rating for ingress protection. It holds certification meeting requirements for SIL 3 and PL e, as well as EU, FM, and CSA approvals, and is certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Actuation types: available with different actuation speeds: quick or slow opening/closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator and visual indicator, fitted bypass or pilot gas valve, or integrated pressure switches DG../VC
