Gas Solenoid Valve - Class A, 500 mbar, IP65, Flow Adjustment

The HONEYWELL KROMSCHRODER VAS2-/50R/LWGR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. The unit features a pilot lamp and flow adjustment capabilities, providing adjustable flow settings.

Certified to applicable EU, FM, and CSA standards, this valve is compatible with systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
