Gas Solenoid Valve - Class A, 500 mbar, IP65, VAS125/-R/NK

The HONEYWELL KROMSCHRODER VAS125/-R/NK is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be in a closed position when not energized and features a pilot lamp and flow adjustment capability. It operates at a maximum pressure of 500 mbar and is certified according to EU, FM, CSA, SIL 3, and PL e standards. The unit is rated IP65 for ingress protection.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: available with options for rapid or gradual opening combined with rapid closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Equipped for electrical connection via terminal block
• Versions available with position indicator/visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
