Gas Solenoid Valve – Class A, 500 mbar, IP65, VCS Series

The HONEYWELL KROMSCHRODER VCS780F05NNWSRB/PPPP/PPPP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It remains closed when de-energized, and supports a maximum operating pressure of 500 mbar. The unit includes an integrated pilot lamp, flow adjustment capabilities, and is rated IP65 for ingress protection. This model has obtained EU certification, FM approval, CSA approval, SIL 3 suitability, and PL e suitability.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass or pilot gas valves, and fitted pressure switches DG../VC
