Gas Solenoid Valve – Class A, 500 mbar, IP65, VCS Series
Mfr # KS88206545
Zoro # G915425551
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VCS780F05NLKR3E/PPPP/PPZ- is a solenoid valve intended for use in applications requiring the shut-off of gas and air lines. Classified as a Class A valve according to EN 161, it operates in a normally closed position when de-energized and is rated for operation at pressures up to 500 mbar. The unit includes an integrated pilot lamp and flow adjustment, with ingress protection rating: IP65. It is certified according to applicable EU, FM, and CSA standards and is suitable for installation in systems requiring compliance with SIL 3 or PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
