Gas Solenoid Valve - Class A, Auto Shut-Off, IP65, 500 mbar

The HONEYWELL KROMSCHRODER VAS1W0/W25R/NW is a Class A solenoid valve rated for automatic shut-off of gas and air per EN 161 standards. The valve is configured to be closed when not energized and features a pilot lamp, flow adjustment, and an IP65-rated enclosure. It is certified to applicable EU, FM, and CSA requirements, and rated for use in applications requiring up to SIL 3 or PL e.

Key features include:

• Maximum operating pressure: 500 mbar
• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
