Gas Solenoid Valve - Class A, Auto Shut-Off, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS1-R/NWGL is a Class A solenoid valve rated for automatic shut-off of gas and air per EN 161 standards. The valve is configured to be closed when not energized and features a pilot lamp and flow adjustment. It is suitable for use with maximum operating pressures up to 500 mbar, rated IP65 according to IEC standard 60529, and certified under applicable EU, FM, and CSA regulations/standards. The unit is suitable for use in systems requiring compliance with SIL 3 or PL e ratings.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
