Gas Solenoid Valve - Class A, EN 161, 500 mbar, IP65

The HONEYWELL KROMSCHRODER VAS1-0/10R/NW is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This valve is rated to comply with EN 161 standards; valve is normally closed when not energized. It is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and adjustable flow settings. The unit carries IP65 rating, EU certification, FM approval, CSA approval; suitable for integration into systems up to SIL 3 or PL e as per manufacturer specifications.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
