Gas Solenoid Valve – Class A, EN 161, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1-0/NW is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. It is rated to comply with EN 161 standards; the valve is normally closed when not energized. The unit is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and adjustable flow settings. This model holds certifications including SIL 3, PL e, FM, and CSA as specified by manufacturer documentation.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing operation: available with quick or slow opening options as specified
• Mains voltage options: compatible with mains voltages of either 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available configurations may include position indicators, visual indicators, bypass/pilot gas valves fittings, or integrated pressure switches
