Gas Solenoid Valve - Class A, EN 161, 500 mbar Max Pressure

The HONEYWELL KROMSCHRODER VAS365/-R/NWSR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be closed in a de-energized state and includes a pilot lamp indicator and adjustable flow settings. It is certified for use with maximum operating pressures up to 500 mbar, carries EU certification, FM and CSA approvals, and is rated for systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
