Gas Solenoid Valve - Class A, EN 161, IP65, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS1-0/NW is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow, meeting EN 161 standards. The valve is configured to be in a closed position when not energized and features a pilot lamp and flow adjustment. It is certified for use in systems up to SIL 3 and PL e, with approvals from FM and CSA, as well as EU certification. The enclosure has an IP65 rating.

Key features include:

• Maximum operating pressure: 500 mbar
• Available sizes: 1 to 9 (DN 10 to DN 125)
• Connection types: threaded or flanged
• Opening/closing options: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Optional versions available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
